12713020-003-2 Revision F.01 – January 2007 SSU-2000 Technical Reference 273
Chapter 5 Antennas
Antenna Kits and Accessories
Table 5-3 through Table 5-5 list the available accessories for GPS antennas with
internal LNA.
Electrical
Power 4.7 to 28 VDC (5 VDC Nominal)
Element Right Hand Circular
Carrier L1 (1545.42 MHz)
Bandwidth 10 MHz
Noise Figure < 2.5 dB
Output Impedance 50 Ω
Gain
Marine 26
Marine 40
Marine 50
26.5 dB ± 3 dB
40 dB minimum
48 dB minimum
Table 5-3. 26 dB L1 GPS Antenna Accessory Kit
Part Number Description
12013076-xxx-0
(xxx = length)
Cable, LMR-400, 10 ft. up to maximum of 190 ft. (Customer
specified length)
112-43400-00-3 Transient Eliminator, 90 Volts, 1.5 GHz, N-Type
12013076-010-0 Cable, LMR-400, 10 ft., Right Angle
400302-0500 Roll, 3M 2150 Weatherproof Tape
Table 5-4. 40 dB L1 GPS Antenna Accessory Kit
Part Number Description
12013076-xxx-0
(xxx = length)
Cable, LMR-400, 70 ft. to maximum of 370 ft.
(Customer-specified length)
112-43400-00-3 Transient Eliminator, 90 Volts, 1.5 GHz, N-Type
12013076-030-0 Cable, LMR-400, 30 ft., Right Angle
12192232-00-2 Adapter, Right Angle Female to Right Angle Male
12010210-000-0 Bracket Assembly, Antenna Mount Right Angle
Table 5-2. Specifications for GPS Antennas with Internal LNA (Continued)
Characteristic Specification
