Symmetricom SSU-2000 Technical Reference

Chapter 2 TL1 Reference
Retrieve JCC Output Parameters
82 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Retrieve JCC Output Parameters
This command returns the settings for the Japan Composite Clock module or port
specified by the aid.
Syntax
RTRV-PRMTR-OUTJCC:[tid]:[aid]:ctag;
Response Format
When the aid specifies a port, the response is:
^^^"aid:bypass,400hz,pstate,pcomp"<cr lf>
where:
 aid = port access identifier
 bypass = allow Clock C selection [ON | OFF]
 pstate = port state (enabled/disable) [ON | OFF]
 400hz = 400 Hz BPV removal [ON | OFF]
 pcomp = phase compensation [0 through 7] where 7 = No compensation and 0 =
2200 ft; the resolution of pcomp values is 275 ft
When the aid specifies a module, the response is:
^^^"aid:bypass,400hz"<cr lf>
^^^"aid:pstate1,pstate2,...pstate20"<cr lf>
^^^"aid:pcomp1,pcomp2,...pcomp20"<cr lf>
where:
Line 1 contains:
 aid = module access identifier
 400hz = 400 Hz BPV removal [ON | OFF]
 bypass = [ON | OFF] for allowing Clock C selection
Line 2 contains:
 aid = module access identifier
 pstate# = port enabled state [0 | 1] (0 is Off, 1 is On) and # is the port number
[1 – 20]
Parameter Value Description
[aid] ALL Retrieves the parameters from all JCC Output modules in
the shelf.
SxAy[-z] Retrieves parameters from the specified JCC Output
module [or port].
