Chapter 6 Alarms and Events
Japan CC Output Module Alarms and Events
328 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Japan CC Output Module Alarms and Events
Table 6-30 lists the alarms and events for the Japan Composite Clock Output
module, and includes the typical response for each alarm or event, it’s event
number, and a description or a suggested corrective action. The SNMP MIB trap is
listed in the Alarm/Event/Trap Description column. Table 6-31 lists the default
parameters for the Japan Composite Clock Output module alarms.
Table 6-30. Japan CC Output Module Alarm and Event Messages
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
000 Hdw Config, Fault If module is installed in slot previously used by a different module
type, use the CONF xAy REMOVE command.
If problem persists, call Symmetricom Global Services
001 Configuration, Fault Redundant configuration mismatch. Re-seat or replace module.
002 Clk-A, Fault Clock module in slot A1 is in warm-up mode or has other problems.
003 Clk-B, Fault Clock module in slot A12 is in warm-up mode or has other
problems.
004 Clk-C, Fault Reference signal is in LOS and both clocks have been removed or
are in warm-up.
005 Clk-D, Fault Only in SDU. Loss of backup clock. Check cable.
006 Clk Selected, Fault No clocks, no output.
007 VCXO, Fault VCXO problems, re-seat or replace module.
008 PLL, Fault No clocks or VCXO. Re-seat and check clocks.
009 Redundant, Fault Failed to sync with master module in redundant pair.
010 400Hz, Fault 400 Hz Sync has failed.
011 4kHz, Fault 4 kHz Sync has failed.
012 PortFlt, Fault, 40000 Indicates which output port is in fault (typically shorted). Repair
short and re-enable port.
129 Install, J/CC Output Module Module Installed.
130 Remove, J/CC Output
Module
Module Removed.
131 Enable, J/CC Output
Module, COML
Module Enabled.
132 Disable, J/CC Output
Module, COML
Module Disabled.
133
Restart, in 5 seconds, COML User request for a module to reboot.
134 Cannot Enable, J/CC Output
Module, COML
Cannot enable module due to configuration error.
