Chapter 5 Antennas
Antenna Kits and Accessories
272 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Table 5-1 lists the item number and provides a brief description of each antenna
Table 5-2 provides specification information for GPS antenna with internal LNA
Table 5-3 through Table 5-6 lists the item numbers and provides a brief
description of the antenna accessories available for the GPS series antennas.
Table 5-2 provides specifications for GPS antennas with internal LNA.
Table 5-1. GPS Antennas with Internal LNA
Part Number Description Minimum Cable Length
99013091-006 26 dB Antenna with 3 m + 3 m cable 3 m (10 ft)
99013091-013 26 dB Antenna with 3 m + 10 m cable 3 m (10 ft)
99013091-033 26 dB Antenna with 3 m + 30 m cable 3 m (10 ft)
99013150-048 26 dB Antenna with 3 m + 45 m cable 3 m (10 ft)
99013073-070 40 dB Antenna with 10 m + 67 m cable 30 m (100 ft)
99013073-120 40 dB Antenna with 10 m + 110 m cable 30 m (100 ft)
99013074-150 48 dB Antenna with 10 m + 140 m cable 76 m (250 ft)
99013074-180 48 dB Antenna with 10 m + 170 m cable 76 m (250 ft)
99013074-230 48 dB Antenna with 10 m + 220 m cable and
20 dB Amplifier
198 m (650 ft)
99013074-300 48 dB Antenna with 10 m + 290 m cable and
20 dB Amplifier
198 m (650 ft)
Table 5-2. Specifications for GPS Antennas with Internal LNA
Characteristic Specification
Mechanical
Mounting 4 holes, 1.75 in x 1.75 in (4.445 cm x 4.445 cm) centers,
0.25 in (0.635 cm) mounting holes
Diameter 3.5 in (88.9 cm)
Height 12.94 in (328.7 cm), including pipe mount
Weight < 3 lbs (1.4 kg)
Environmental
Temperature –40°C to +75°C
Relative Humidity 100% Non-Immersed
Altitude
200 ft. (60 m) below sea level to 13,000 ft. (3962 m) above sea level
