12713020-003-2 Revision F.01 – January 2007 SSU-2000 Technical Reference 325
Chapter 6 Alarms and Events
DS1 Output Module Alarms and Events
194 ZS, On, COML User changed output framing type.
195 DS1 LEN, Port[0-5],
len=133ft, COML
User changed output line length.
199 CRC, On, COML User has changed output framing type.
201 SSM Bit, 8, COML User has changed output SSM bit position (E1 only).
202 Min Clk Level, ACQ, COML User has changed Minimum Clock Level to turn on outputs.
203 Bypass, ON, COML User has changed Bypass mode of operation
204 Squelch, Port[0-5], 0, COML User has changed squelch PQL level.
205 Delay, Port{1-4], 1375ft,
COML
CC signal phase offset settings have been changed for the port
shown.
224 IoName, Set User has changed the port name.
252 Alm Level, (1), Min, COML User has changed time to elevate alarm level.
253 Elevate Time, 86400 sec,
COML
An alarm elevation time change.
254 Setup, User Default, COML User has reset setup to user-defined default values.
Table 6-27. DS1 Output Module Alarm Defaults
ID Description Alarm Level
000 Redundant Major
001 Module Match Major
002 Clk-A Major
003 Clk-B Major
004 Clk-C Major
005 Clk Level Major
006 Clk Selected Major
007 PortFlt Major
008 VCXO Major
009 PLL Major
010 Configuration Major
011 Hdw Config Major
012 Clk-D Major
Table 6-26. DS1 Output Module Alarm and Event Messages (Continued)
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
