12713020-003-2 Revision F.01 – January 2007 SSU-2000 Technical Reference 301
Chapter 6 Alarms and Events
Communication Module Alarms and Events
Table 6-7. Basic +SNMPv3 and Basic +NTP + SNMPv3 Communications Module Alarm and Event Messages
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
000 Communication, Fault Unable to communicate with other modules. Re-seat modules.
001 InterCommunication, Fault Identifies master output controller. No action necessary.
002 Power-A, Lost
Verify that the fuse for Power
A is properly installed and not OPEN.
Verify that Power Bus A is providing –48 VDC to the unit. If no
power is connected to the Power A input and there is no plan to
connect power, issue the command AL 10-1 IG at the prompt.
003 Power-B, Lost
Verify that the fuse for Power
B is properly installed and not
OPEN.
Verify that Power Bus B is providing –48 VDC to the unit. If no
power is connected to the Power B input and there is no plan to
connect power, enter the command AL 10-1 IG at the prompt.
004 SPI Watchdog, Timeout Unable to communicate with other modules. Re-seat module.
005 Shelf #2 Comm, Lost Unable to communicate with Expansion Shelf 2. Check cables.
006 Shelf #3 Comm, Lost Unable to communicate with Expansion Shelf 3. Check cables.
007 Shelf #4 Comm, Lost Unable to communicate with Expansion Shelf 4. Check cables.
008 Shelf #5 Comm, Lost Unable to communicate with Expansion Shelf 5. Check cables.
009 Detect Mdl Removed, Fault A module has been removed from the system or is not responding
to Comms module queries. Replace the removed module with the
same type, or issue the command CONFIG xAy REMOVE to
remove the module information from the system database.
105 KeepAlive, SSU2000 The Keep Alive function has been enabled/ disabled.
129 Install, Comm Module The Comms module has been installed.
130 Remove, Comm Module The Comms module has been removed.
131 Enable, Comm Module,
COML
The Comms module has been enabled.
132 Disable, Comm Module,
COML
The Comms module has been disabled.
133 Restart, in 5 seconds,
COML
The Comms module has been rebooted (Warm boot).
144
Log In, DAVE, COML, level: 2
User at indicated level has logged in.
145
Log Out, TIM, COML, level: 2
User at indicated level has logged out.
146
Auto Out, TIM, COML, level: 3
System automatically logging out a user.
147 Msg, <HELLO BILL>, COML Message sent from a user.
148 Not Acknowledged, 1A01 Module configuration could not be obtained.
150 Module Status, Fault, 1A04 Module did not boot properly.
