Chapter 6 Alarms and Events
DS1/E1 Input Module Alarms and Events
134 Cannot Enable, Input
Module, COML
Internal firmware conflict. Restart module; if the problem persists,
call Symmetricom Global Services.
144 Zero Phase, B, COML User has forced the phase to be cleared.
145 Rcv Pql Chg, 3, old=4 Input has received a different PQL.
146 Phase Buildout, 334000,
335000, Clk-B
Input performed phase buildout and difference in Phase that cause
PBO.
193 DS1 Framer, ESF, COML An Input framer setup change.
194 E1 Framer, CCS, COML An Input framer setup change.
195 Freq, 10 MHz, COML User changed input framer setup.
196 ZS, On, COML User changed input framer setup.
197 SSM, Off, COML User changed input SSM capability.
198 CRC, On, COML User changed CRC setup.
199 Port, Disable, COML User Enabled | Disabled input port.
200 SSM, Auto, COML User changed SSM setup.
201 Priority, 5, COML User changed input priority level.
202 SSM Bit, 4, COML User changed SSM Bit location (E1 only).
203 Prov PQL, 5, COML User changed input provisioned PQL.
204 MTIE Err Limit, T100, L1,
550, COML
User changed input MTIE limits (L1 | L2).
205 Gain, On, COML User changed the input gain control.
206 CSFlt, Off, COML User changed input Cesium Fault control.
207 Err Cnt, BPV, 16, COML Signal Alarm Error Count (LOS, AIS, OOF, BPV, or CRC).
208 Clr Cnt, OOF, 5, COML Current Signal Alarm Clear Count (LOS, AIS, OOF, BPV, or CRC).
209 Freq Err Limit, Clk-A, 100,
COML
The frequency error limit settings have been changed.
210 Freq Clr Limit, Clk-A, 800,
COML
The frequency clear limit settings have been changed.
211 MTIE Clr Limit, T100, L1,
500, COML
The MTIE error limit settings have been changed.
212 MTIE Limit, DS1, COML,
Setting
The MTIE clear limit settings have been changed.
213 PBO, Report, COML Phase Build-out system response has been changed to the
indicated setting.
214 Freq Tau, Clk-A, 400, COML The frequency TAU limits have been set.
Table 6-10. DS1/E1 Input Module Alarm and Event Messages (Continued)
