Xerox Phaser 3610 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-42
116-361
PCI Error
Power Off/On
Error 116-361
Power Off/On
<PCI Bus #0 Error Detected>
Cause:
PCI Bus #0 Uncorrectable Error Detected.
(Connected with Remora EX(x4 port))
FIP 1. 311
116-362
PCI Error
Power Off/On
Error 116-362
Power Off/On
<PCI Bus #0 Host Bridge Controller Error>
Cause:
PCI Bus #0 Host Bridge Controller Error. (Con-
nected with Remora EX port)
FIP 1. 312
116-363
PCI Error
Power Off/On
Error 116-363
Power Off/On
<PCI Bus #1 Host Bridge Controller Error>
Cause:
PCI Bus #1 Host Bridge Controller Error. (Con-
nected with Remora EX port.)
FIP 1. 313
116-364
Clock Error
Power Off/On
Error 116-364
Power Off/On
<Timer Fail>
Cause:
Timer error is detected.
FIP 1. 314
116-366
PCI Error
Power Off/On
Error 116-366
Power Off/On
<PCI Bus #1 Error Detected>
Cause:
PCI Bus #1 Uncorrectable Error Detected.
(Connected with RemoraEX(x1 port))
FIP 1. 315
116-368
PCI Error
Power Off/On
Error 116-368
Power Off/On
<PCI Error Messages received from Bus #0 -
Device #1>
Cause:
Remora EX PCI x1 port Error. (Device ID 0x65
(x1))
FIP 1. 316
116-369
PCI Error
Power Off/On
Error 116-369
Power Off/On
<PCI Error Messages received from Bus #0 -
Device #0>
Cause:
Remora EX PCI x4 port Error. (Device ID 0x64
(x4))
FIP 1. 317
116-390
NVRAM Error
Power Off/On
Error 116-390
Power Off/On
<ESS NVRAM1 SIZE And ID Check Fail>
Cause:
Detected by consistency check between NVRAM
size requested by the system and actual size and
consistency check of ID recorded at the first
power-on.
FIP 1. 318
Status
Code
(3610)
LCD Message Name/Description of Error FIP

Xerox Phaser 3610 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Maximum duty cycle	110000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Network ready	Yes
Security algorithms	EAP, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint
Internal memory	512 MB
Processor frequency	400 MHz
Maximum internal memory	1024 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
Optional connectivity	Wireless LAN
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	52 W
Power consumption (printing)	686 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 28 °C
Operating relative humidity (H-H)	20 - 70 %
Product color	Blue, White

Weight and Dimensions

Depth	426 mm
Width	393 mm
Height	315 mm
Weight	13000 g
