Xerox Phaser 3610

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual3-16
18
Is the connection terminal of the Xerographic
Connector Assembly damaged?
Replace (REP 3.3
Xerographic Connector
Assembly), then go to
step 19.
Go to Step 19.
19 Is the image printed correctly?
Troubleshooting
complete.
Go to step 20.
20
Reseat the MCU PWB.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 21.
21
Reseat the ESS PWB.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 22.
22
Reseat (REP 3.4 Transfer Roller Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Go to step 23.
23
Replace (REP 3.4 Transfer Roller Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Go to step 24.
24
Replace the Drum Cartridge.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 25.
25
Reseat the HVPS.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 26.
26
Replace (REP 3.1 ROS Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Replace (REP 5.7 HVPS
(3610) / REP 5.8 HVPS
(3615)).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
