Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-37
077-107 -
<Duplex Regi On Jam>
Cause:
After the Invert Clutch turned ON, the Regi. Sen-
sor did not turn ON within the specified time.
FIP 1. 258
077-108 -
<Exit Off early Jam>
Cause:
After the Exit Sensor turned ON, the Exit Sensor
turned OFF before the specified time.
FIP 1. 257
077-109 -
<Exit Off Jam>
Cause:
After the Regi. Sensor turned OFF, the Exit Sensor
did not turn OFF within the specified time.
FIP 1. 257
077-215
Duplexer Error
Power Off/On
Error 077-215
Power Off/On
<IOT Duplexer Error>
Cause:
Duplex Unit Configuration error is detected.
FIP 1. 285
077-217
Duplexer Error
Power Off/On
Error 077-217
Power Off/On
<Duplex Miss Configuration>
Cause:
Duplex Unit Configuration error is detected.
FIP 1. 285
077-300
Front Cover Open
Close Front Cover
<IOT Cover Front Open>
Cause:
Beep sounds after Front Cover remains open for 3
minutes.
FIP 1. 286
077-304
Rear Door Open
Close Rear Door
<IOT Cover Rear Open>
Cause:
The Rear Cover is open.
FIP 1. 287
077-312
Tray Config Err.
Power Off/On
Error 077-312
Power Off/On
<Tray Configure Error>
Cause:
Tray configuration error was detected.
(including all of the wrong configurations)
FIP 1. 288
091-914
Drum Error
Reseat Drum
Error 091-914
Reseat Drum
<IOT Drum Communication Fail>
Cause:
Communication failure with Drum CRUM was
detected.
FIP 1. 290
Status
Code
(3610)
LCD Message Name/Description of Error FIP

Xerox Phaser 3610 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Maximum duty cycle	110000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Network ready	Yes
Security algorithms	EAP, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint
Internal memory	512 MB
Processor frequency	400 MHz
Maximum internal memory	1024 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
Optional connectivity	Wireless LAN
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	52 W
Power consumption (printing)	686 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 28 °C
Operating relative humidity (H-H)	20 - 70 %
Product color	Blue, White

Weight and Dimensions

Depth	426 mm
Width	393 mm
Height	315 mm
Weight	13000 g
