7-36
Wire harness
12. Connect:
•Holder “1”
•ETV coupler “a”
• Rectifier/regulator coupler “b”
•YDIS coupler “c”
• Low-pressure fuel pump relay coupler “d”
A
B
13. Connect:
•Holder “1”
• Low-pressure fuel pump coupler “a”
• High-pressure fuel pump coupler “b”, “c”
• Intake air pressure/temperature sensor
coupler “d”
14. Connect:
• Ground lead “a”, “b”, “c”
TIP:
Connect the ground leads so that they contact
the stoppers. Make sure to match the num-
bers “d” on the ground leads to the numbers
“e” on the oil filler neck.
15. Connect:
• Crankshaft position sensor coupler “a”
16. Install:
• Holder bracket
•Holder
A. F450A/FL450A/XF450
B. F400A/FL400A/XF400
a
b
c
d
e
a
b
c
d
e
11
fff
gg
fff
a
b
d
c
1
a
b
d
c
1
a
b
c
d
1
a
b
c
d
1
bb
cc
dd
aa
b
c
d
a
111
111
1
2
3
1
2
3
2
3
b
c
d
e
a
a
