ABB RELION REX640 Technical Manual

DUPPDPR Output signals
Table 993: DUPPDPR Output signals
Name Type Description
OPERATE BOOLEAN Operate
START BOOLEAN Start
4.8.1.8 DUPPDPR Settings
Table 994: DUPPDPR Group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Start value 0.01...2.00 xSn 0.01 0.10 Start value
Operate delay time 40...300000 ms 10 40 Operate delay time
Table 995: DUPPDPR Non group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Operation
1=on
5=off
1=on Operation On/Off
Table 996: DUPPDPR Non group settings (Advanced)
Parameter
Values (Range) Unit Step Default Description
Measurement
mode
1=PhsA, PhsB, PhsC
2=Arone
3=Pos Seq
4=PhsAB
5=PhsBC
6=PhsCA
7=PhsA
8=PhsB
9=PhsC
3=Pos Seq Selection of power
calculation method
Reset delay time 0...60000 ms 10 20 Reset delay time
Pol reversal
0=False
1=True
0=False Reverse the defini-
tion of the power
direction
Disable time 0...60000 ms 1000 0 Additional wait
time after CB clos-
ing
4.8.1.9 DUPPDPR Monitored data
Table 997: DUPPDPR Monitored data
Name
Type Values (Range) Unit Description
START_DUR FLOAT32 0.00...100.00 % Ratio of start time / op-
erate time
P FLOAT32 -160.000...160.000 xSn Active power
Q FLOAT32 -160.000...160.000 xSn Reactive power
S FLOAT32 0.000...160.000 xSn Apparent power
Table continues on the next page
1MRS759142 F Protection functions
REX640
Technical Manual
1061
