7.2.6.2 ESDCSSWI Output signals
Table 1317: ESDCSSWI Output signals
Name Type Description
TRV_T_OP_ALM BOOLEAN Switch open travel time ex-
ceeded set value
TRV_T_CL_ALM BOOLEAN Switch close travel time ex-
ceeded set value
OPR_ALM BOOLEAN Number of switch operations
exceeds alarm limit
OPR_LO BOOLEAN Number of switch operations
exceeds lockout limit
MON_ALM BOOLEAN Switch not operated for long
time alarm
OPENPOS BOOLEAN Apparatus open position
INVALIDPOS BOOLEAN Apparatus position is invalid
CLOSEPOS BOOLEAN Apparatus closed position
7.2.7 ESDCSSWI Settings
Table 1318: ESDCSSWI Non group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Operation
1=on
5=off
1=on Operation Off / On
Open alarm time 40...30000 ms 10 15000 Alarm level setting
for open travel time
in ms
Close alarm time 40...30000 ms 10 15000 Alarm level setting
for close travel time
in ms
Alarm Op number 0...99999 1 200 Alarm limit for
number of opera-
tions
Inactive Alm days 0...9999 1 2000 Alarm limit value of
the inactive days
counter
Travel time Clc
mode
1=From Cmd to Pos
2=From Pos to Pos
2=From Pos to Pos Travel time mode
selection
Lockout Op num-
ber
0...99999 1 300 Lock out limit for
number of opera-
tions
1MRS759142 F Condition monitoring functions
REX640
Technical Manual
1381
