R5905948 /12 Event Master Devices 139
Next to the configuration name is the name of the Destination where the output is assigned. If the Output is not
assigned to any Destination, then the name will be “N/A”.
The software by default names outputs as [ConnectorType] “Output 1, 2, 3...” The user can rename
each output by double clicking on the name and type in the new name in the blue box.
How to add an Output
Output configurations can be added manually to unassigned connectors.
1. Select the Detail View tab in the system diagram area.
2. Select any unassigned connectors from the detail view.
Selected connector(s) will be highlighted blue.
Note: If the output is 4K provided by the quad SDI connectors, the 4 SDI connectors need to be
selected.
Connector(s) is immediately highlighted in blue.
3. Click on either the Add Single Output or Add Multiple Outputs button, depending on if single or multiple
connectors need to be added as a single output, or if multiple connectors are to be created as multiple
outputs.
4. The created outputs are now added to the output list and can be further configured by individually selecting
them, then using the adjust tab to make any necessary changes.
How to delete Output
1. Click on the Delete Output(s) button
The Delete Output(s) button is replaced by the Delete Selected button (highlighted in red).
2. Click on the corresponding connector in the graphical area.
or
click in the “x” on the right hand side in the output configuration list.
Connector(s) will be immediately highlighted in blue.
3. The deletion is completed by clicking the Delete Selected button.
Multiple connector configurations can be selected to be deleted together.
You can only delete Output Configurations that are not assigned in Destinations.
How to adjust output configurations
Adjustments to outputs are performed in the “Adjust” panel:
1. Select the output from the configuration list
or
click on the connector graphic.
An output is selected.
2. Click on the Adjust tab that is on the top of the Adjustment area.
EM GUI orientation
