R5905948 /12 Event Master Devices 159
How to delete Destination
1. Click on the Delete Destination(s) button. The Delete Destination(s) button is replaced by the Delete Selected
button (highlighted in red) and the unit diagram is greyed out, except the area dedicated to destinations
(Screen and Aux).
2. Click on destination in the graphical area.
or
Click on the “x” on the right hand side in the destination configuration list.
Destinations selected for deletion are outlined in red.
Image 6-42: Delete selected Destination(s)
3. The deletion is completed by clicking the Delete Selected button.
Note: Any output can be deleted from a destination at any time. For example, if the output that is
automatically assigned to a destination is not the desired one, then it can be deleted by using the
Destination Adjust tab.
Note: All destinations can be deleted at the same time by clicking the “Select All” button.
How to access to the Destination configuration adjustments
Adjustments to Destinations (Screen, Aux, Super, or Super Aux) are performed in the “Adjust” panel:
1. Select the destination from the configuration list.
or
Click on the graphic representation of the destination in the Diagram area.
A Destination is selected.
2. Click on the Adjust tab that is on the top of the Adjustment area.
EM GUI orientation
