Barco Event Master E2 Series User Manual

R5905948 /12 Event Master Devices 201
List View
Thumbnail View
Inputs (List view)
Inputs (List view)
• Resolution: This is the resolution of the Input
signal.
• The LED color indicates the status of the input:
- Red: Sync is missing or invalid format.
- Green: Sync is valid.
•
Refreshes the Input thumbnail (in Thumbnail
View) from the Input source.
•
Freezes the Input.
•
Allows a snapshot to be taken and stored as a
Still.
•
Adds Sources based on the inputs. A total of
256 are allowed per input.
•
Copies the Source into a new Source and
adds it in the list.
Inputs (Thumbnail view)
Thumbnails can be added by clicking the refresh icon on the required input, or the "Refresh All" button.
Thumbnails may also be manually uploaded to the EMTS by clicking on the thumbnail area while the list is in
thumbnail view.
EM GUI orientation
