Operating the transceiver

Manpack Transceiver 2110 series Reference Manual 85

Pausing scanning

To pause scanning:

1 Do one of the following:

• To pause scanning on the current channel/mode, press .

• To pause scanning and scroll to another channel/mode, press or .

The channel/modes through which you can scroll are those in the network or

networks that were being scanned. They are not listed alphabetically but in the order

in which they were being scanned.

If you do not press a key within 30 seconds, the transceiver automatically resumes

scanning.

1 While scanning is paused, do one or more of the following:

• To speak, hold down PTT.

• To resume scanning immediately, press .
