Making and receiving calls

Manpack Transceiver 2110 series Reference Manual 207

Selecting the best channel in an ALE/CALM network

In order to select the best channel based on LQA information stored in the transceiver,

you must provide the context of the best channel, that is, the address that you want to call

and the network in which you want to make the call.

To select the best channel:

1 Press SCAN to switch off scanning.

1 Press CALL.

1 Type the address of the station for which you want to find the best channel.

1 Select any valid call type for the address entered.

1 Select the ALE/CALM network in which you want to make the call.

1 At the channel/mode prompt, press .

The best channel is selected.

NOTE

You can select the best channel in an ALE/CALM network if you have the

MIL-STD-188-141B ALE option installed (2110 only).
