Hot key examples
Manpack Transceiver 2110 series Reference Manual 389
Example 2: displaying an information screen
The time and LQA screens are information screens. You can view the information on
these screens but you cannot change it. This example shows you how to create a macro
to display the time screen in the Control List.
When you run this macro, the transceiver:
• goes to the Time Screen entry in the Control List
• briefly displays the current time and date
• returns you to the screen you were on
To create this macro:
1 Log in to admin level (for help see page 128, Logging in to admin level from user
level).
1 Press until Main Menu is displayed.
1 Scroll to Control, then press .
1 Scroll to Time..., then press .
1 Scroll to Screen, then press .
1 Hold to open the List Manager.
1 Scroll to Macros..., then press .
1 Scroll to Create macro, then press .
The transceiver asks you to select the timing with which the macro operates.
1 Scroll to Before pause, then press .
1 Press the key to which you want to assign the new macro.
1 Scroll to the macro you want to have in the list immediately after the new macro,
then press .
1 Type a name for the macro, then press .
The macro is created and assigned to the key, and the List Manager remains open.
NOTE
This macro displays an information screen and does not change any
values, so you can select Before pause or After pause. The end
result is the same.
