Get Status calls

Manpack Transceiver 2110 series Reference Manual 397

Table 60: Information retrieved in an open Diagnostic Get Status call

Information

received

Description

RXnn.n Battery voltage in receive

TXnn.n Battery voltage in transmit

S1=nn Signal strength of received call

SWR=n.n SWR of the antenna

Vn.nn Transceiver power

Base|Mobile Transceiver antenna type

FwrPower=nn Forward power

RevPower=nn Reflected power

Tcvr930|2000 Transceiver type

Vn.nn Firmware version

T=nn Temperature (°C)

ID=nnnnnn Last Called ID
