The 2110 series Manpack Transceiver

Manpack Transceiver 2110 series Reference Manual 21

The front panel

Figure 3: The front panel (2110 model shown)

User controls

The user control area comprises:

• an LCD

• navigation keys ( , , , , )

• volume controls ( , )

• soft function keys (F1, F2, F3) corresponding to the function displayed on the front

panel screen

• alphanumeric keys (0 to 9,

, #)

• emergency key ( )

• power key ( )

NOTE

The 2110v Manpack Transceiver uses a 5-way connector in place of the

19-way GPIO connector ( ) on the 2110 Manpack Transceiver.

NOTE The GPS connector is optional for the 2110 Manpack Transceiver.

interface

connectorsuser controlsHF antennas

internal

GPS

antenna

(if fitted)

internal

speaker

earth

terminal

VIEW

TUNE

ABC

CLAR

MODE

DEF

FREE

GHI

JKL

PWR

PRS

TUV

SEC

GPS

CALL

LOGS

EASI

TALK

GPS
