Manpack Transceiver 2110 series Reference Manual 395
Appendix B Get Status calls
Diagnostic and Configuration Get Status calls
When you make a Get Status call, you need to specify the type of status information you
want to retrieve from the remote station (see Table 60, Table 58 and Table 61). You are
prompted by the transceiver to specify the type of information during the Get Status call.
Making a Codan Diagnostic Get Status call
Codan diagnostic information may only be retrieved from another transceiver by using a
Get Status call in an ALE/CALM or Codan Selcall network. It contains the information
listed in Table 58, or Table 59 for older Codan HF transceivers. Transceivers from other
vendors may obtain diagnostic information from a 2110 Manpack Transceiver by
sending an AMD message containing #CMD 1 in a Plain network.
To obtain Codan diagnostic information:
1 Press CALL.
1 Type the address of the station you want to call, scroll to Get Status? for the call
type, then press CALL.
1 Scroll to 1: Diagnostic, then press CALL.
1 Scroll to an ALE/CALM or Codan Selcall network, then press CALL.
1 Scroll to the channel/mode combination you want to use, then press CALL.
Table 58: Information retrieved in a Codan Diagnostic Get Status call made to
a Codan HF transceiver
Information
received
Description
RXnn.n Battery voltage in receive
TXnn.n Battery voltage in transmit
S1=nnn Signal strength of received call (dBµV)
S2=nnn Signal strength 2 seconds after call was received (dBµV)
SWRn.n SWR of the antenna
Pnnn Power output of the transmitter (W)
Tnn Temperature (°C)
