Connectors
Manpack T
ransceiver 21
10
series
Reference Manual
35
7
Pinout
s of the 5-way connector (21
10v
only)
Figure
58:
Front view of the
5-way connector (21
10v
only)
T
able
46:
Pinouts of the 5-
way connector (21
10v
only)
Pin no.
Function
Input/output
Signal level
A
P
ower in for charging battery
Input
15.5
V
DC approx.
1
A maximum, current
limiting
B
RS232 Tx data
Output
RS232
C
Morse
Input
Active low
D
G
round
0
V
DC
E
RS232 Rx data
Input
RS232
A
B
CD
E
372
374
