Preparing the transceiver for use

Manpack Transceiver 2110 series Reference Manual 35

Selecting an appropriate tactical antenna

Use the following table as a guide to selecting a tactical antenna that is appropriate for

your communication requirements.

Table 8: Selection guide for tactical antennas

Tactical antenna Communication distance See...

0 to 100 km

(0 to 60 mi)

100 to

500 km

(60 to

300 mi)

up to

2000 km

(up to

1200 mi)

up to

5000 km

(up to

3000 mi)

Tape and Knock-

down Whips (ground wave

only)

page 36, Tactical

whip antennas

3m (10ft)

Collapsible Whip (ground wave

only)

Long Wire and

Adaptor

page 37, Tactical

long wire antenna

and adaptor

End-fed Broadband page 37, Tactical

end-fed broadband

antenna

Broadband Dipole page 38, Tactical

broadband dipole

antenna

Wire Dipole page 38, Tactical

wire dipole antenna

NOTE

For specific information on the deployment of a tactical antenna see the

Quick Reference Card provided with the antenna.
