Codan 2110 series - Figure 57: Front View of the External GPS Antenna Connector (2110 Only); Table 45: Pinouts of the External GPS Antenna Connector (2110 Only)

To Next Page

To Previous Page

Connectors

356 Manpack Transceiver 2110 series Reference Manual

Pinouts of the external GPS antenna connector (2110 only)

The external GPS antenna connector provides an interface for GPS signals. It

automatically detects signals and sends these to the internal GPS receiver for processing.

Figure 57: Front view of the external GPS antenna connector (2110 only)

For specifications of this connector see Table 55 on page 383.

Table 45: Pinouts of the external GPS antenna connector (2110 only)

Connection Function

Centre pin Active GPS antenna

Sleeve GPS antenna ground
