Specifications

Manpack Transceiver 2110 series Reference Manual 383

Weight Transceiver only: 2.9 kg

(6.4 lb)

17 Ah LiFePO

battery

pack:

2.6 kg

(5.7 lb)

13 Ah NiMH battery

pack:

2.9 kg

(6.4 lb)

8 Ah NiMH battery

pack:

2.1 kg

(4.6 lb)

7 Ah SLA battery pack: 3.2 kg

(7.1 lb)

Sealing IP68 (immersion for 1 hour at a depth of 1 m (3 ft))

Table 55: Specifications for the GPS connector

Item Specification

DC level 3.3 V ±10%

Current limit 150 mA ±50 mA

Operating current 5 to 30 mA

10 mA nominal

Table 54: Specifications for the 2110 series Manpack Transceiver (cont.)

Item Specification
