Making an open Diagnostic Get Status call
Open diagnostic information may only be retrieved from another transceiver by using a
Get Status call in an Open Selcall network. It may contain all or part of the information
listed in Table 60.
To obtain open diagnostic information:
1 Press CALL.
1 Type the address of the station you want to call, scroll to Get Status? for the call
type, then press CALL.
1 Scroll to 1: Diagnostic, then press CALL.
1 Scroll to an Open Selcall network, then press CALL.
1 Scroll to the channel/mode combination you want to use, then press CALL.
Table 59: Information retrieved in a Codan Diagnostic Get Status call made to
a Codan 9323 or 9360 transceiver
Information
received
Description
RX=nn.nV Battery voltage in receive
TX=nn.nV Battery voltage in transmit
S1=nnnµV Signal strength of received call (dBµV)
S2=nnnµV Signal strength 2 seconds after call was received (dBµV)
GAIN=nnn RF gain on or off
SWR=n.n SWR of the antenna
PWR=nnnW Power output of the transmitter (W)
