Preparing the transceiver for use
30 Manpack Transceiver 2110 series Reference Manual
To charge a battery:
1 Use the information in Table 6 to connect the charger using the correct cable to the
transceiver or battery pack.
1 Connect the charger to an appropriate power source.
If the transceiver is operational during charging, the battery status indicator on the
front panel screen shows that the battery pack is charging. When charging is
complete, the battery status indicator is full.
WARNING
The battery pack should be charged with the connector facing upward and
the vents clear of obstructions so that any gas created during the charging
process is released.
CAUTION
Provide clear notification that charging is underway. Ensure there is
adequate ventilation around the battery during charging.
NOTE
If the voltage of the battery is below 10 V, the OUTPUT LED on the
charger flashes orange for a period of time before charging commences.
The LED may also flash during this period.
Table 6: Cable information for battery chargers
Charger type Codan part number of output cable
To front panel To battery pack
19-way 5-way
3121 08-06215-001 08-06738-001 08-06214-001
3122 08-06215-001 08-06738-001 08-06214-001
3123 08-06214-001
3522 08-07102-001 Not available 08-07101-001
3523 08-07103-001
Solar battery charger 08-06215-001 08-06738-001 08-06214-001
Hand-powered battery
charger
08-06215-001 08-06738-001 08-06214-001
NOTE
The 3123 or 3523 Fast AC Battery Charger cannot be used to
charge a battery pack via the front panel of the transceiver.
NOTE
If you are using a solar battery charger, ensure that the panel is facing
the sun.
NOTE
If you are using a hand-powered battery charger, strap it to a tree, or
attach it to the stand provided.
