Hot keys
Manpack Transceiver 2110 series Reference Manual 341
Creating a macro and assigning it to a hot key
To create a macro and assign it to a hot key:
1 Decide on the task you want the hot key to perform.
1 Navigate to the list, entry or setting in which the task begins.
For example, if the task is to open a list at a particular entry, navigate to that entry. If
the task is to enter a particular value in a setting, navigate to the setting and enter the
value.
1 Hold to open the List Manager.
1 Scroll to Macros..., then press .
1 Scroll to Create macro, then press .
The transceiver prompts you to select the action you want the macro to perform
and/or the timing with which you want it to operate.
1 If you are prompted to select the action you want the macro to perform, scroll to the
option you want, then press .
Table 41 on page 342 explains each option.
1 Scroll to the timing with which you want the macro to operate, then press (see
Table 41).
1 Press the key to which you want to assign the macro.
To assign the macro to the Unassigned entry in the Keypad List, press .
You cannot assign the macro to the Special entry.
The macros assigned to the key or entry are displayed. At the end of the list, or if
there are no macros assigned to the key or entry, <end> is displayed.
If you pressed the wrong key, press to go back a step, then press the key to which
you want to assign the macro.
1 Scroll to the macro you want to have in the list immediately after the new macro,
then press .
To insert the macro at the end of the list, scroll to <end>, then press .
1 Type a name for the new macro, then press .
The macro is created and assigned to the key. The List Manager remains open.
NOTE
The information for which you are prompted and the options from
which you can select vary according to the list, entry or setting from
which you began.
NOTE For help with entering text see page 72, Entering and editing text.
