Manpack Transceiver 2110 series Reference Manual 269
15 The Keypad List
The Keypad List stores information about the keys on the front panel and the events that
occur when the keys are pressed.
The Keypad List contains an entry for each key on the front panel. Each entry stores a
list of the macros assigned to the key, and a list of the upper-case, lower-case and
numeric characters that you can enter using the key (see Table 36).
It also contains two entries that you can use to create and maintain macros. The Special
entry contains a number of macros that you cannot create from the front panel, but can be
copied and assigned to any key. The Unassigned entry is a place where you can store
macros for which you have no immediate use. For more information on macros and the
Special and Unassigned entries see page 337, Hot keys.
NOTE
The transceiver is shipped with the Keypad List hidden at admin level. To
display the list see page 131, Hiding and showing information.
NOTE
There are no entries for the CALL, , , , , , and keys as
you cannot assign macros to these keys.
Table 36: Entries in the Keypad List
Name of key Macros
assigned to key
Upper case Lower case Numeric
# Call Logs - Out Toggles upper-case, lower-case and numeric text
entry
* Easitalk . , ’ ? ! & # $
* ( ) - + /
. , ’ ? ! & # $
* ( ) - + /
.
0 Channel Screen 0 space 0 space 0
1QZ Manual Tune QZ1 qz1 1
2ABC Clarifier ABC2 abc2 2
3DEF Next Mode DEF3 def3 3
4GHI Free Rx GHI4 ghi4 4
5JKL JKL5 jkl5 5
6MNO Tx Pwr MNO6 mno6 6
7PRS Mute Type PRS7 prs7 7
8TUV Secure TUV8 tuv8 8
9WXY GPS WXY9 wxy9 9
Emergency Call Emergency
F1 Mute
F2 Call Key
