Reference Manual
25
Handset
The 21
10
series Manpack Transceiver supports
standard audio accessories using H-229
type connectors. The handset is
a standard issue, lightweight
, tactical H-250/U type, with
built-in earphone, noise-cancel
ling microphone, and PTT button.
It is connected to the
6-way connector on the front panel of the transceiver
.
Figure
4:
The handset
earphone
microphone
PTT
40
42
