Using the 9350 Automatic Tuning Whip Antenna with a 2110 Manpack Transceiver
Manpack Transceiver 2110 series Reference Manual 61
Noise interference Noise interference by
other equipment
Identify the source of interference by switching off other
equipment. If possible, move the transceiver and/or
antenna away from the noise source.
Inadequate earthing of
the transceiver
Improve the earth of the transceiver by connecting an
earthing strap (braid or copper strip) from the earth screw
of the transceiver to the earthing point, keeping the strap
as short as possible.
No power The internal fuse of
the transceiver has
blown
Replace the fuse.
Poor connections Check that the battery is connected correctly to the
transceiver.
Battery not supplying
the correct voltage, or
is in poor condition
Check battery supply (see page 50, Checking the vehicle
battery).
Faulty cables and/or
connectors
Check that the cables and connectors between all items of
equipment are securely connected and not damaged. If the
cables or connectors are faulty, contact your Codan
representative.
Poor radiation
efficiency
Poor installation Improve the earth connection (see page 48, Grounding
the antenna).
Incorrect positioning
of the antenna
Check the position of the antenna, ensuring that the
vehicle body is not acting as a shield.
The antenna may not
be earthed correctly
Improve the earth connection (see page 48, Grounding
the antenna).
SWR is bad The SWR
measurement may
have been performed
at the transceiver unit
rather than at the
antenna
Ensure the SWR meter is connected to the coaxial line at
the base of the antenna to achieve an accurate reading (see
page 63, Standing wave ratio).
The antenna may not
be positioned
correctly
Check the position of the antenna, ensuring that the
vehicle body is not acting as a shield. With an SWR meter
in place, alter the position of the antenna to achieve best
forward-radiated power (see page 63, Standing wave
ratio).
Faulty coaxial cable
or control cable
Replace faulty cables.
The antenna may not
be earthed correctly
Improve the earth connection (see page 48, Grounding
the antenna).
Table 18: Possible faults in the installation (cont.)
Symptoms Possible causes Action
