A
B
C
D
E
F
G
H
L
M
N
P
51098/1098S - M.Y. 2007 - edition 00
General summary
5 - Gearchange control 23
Removal of the complete gearchange control 24
Disassembly of the gearchange control 25
Refitting the gearchange control 26
Section G
Wheels - Suspension - Brakes 0
1 - Front wheel 3
Removal of the front wheel 4
Overhauling the front wheel 6
Refitting the front wheel 9
2 - Front fork (1098) 11
Removal of the front forks 12
Overhauling the front forks 13
Refitting the front forks 20
3 - Hydraulic front brake 22
Maintenance operations 23
Removal of the front brake system 24
Refitting the brake discs 26
Overhauling the front brake components 27
Refitting the front brake system 28
4 - Rear wheel 30
Removal of the rear wheel 31
Overhauling the rear wheel 32
Refitting the rear wheel 33
5 - Rear swingarm 34
Removal of the rear eccentric hub 35
Removal of the rear eccentric hub 37
Removal of the swingarm 39
Inspecting the swingarm pivot shaft 41
Overhauling the rear swingarm 42
Refitting the swingarm 46
6 - Hydraulic rear brake 48
Removal of the rear brake caliper 49
Removal of the rear brake disc 50
Refitting the rear brake caliper 51
7 - Rear suspension 52
Rear suspension system 53
Removal of the rear shock absorber 54
Overhauling the rear shock absorber 55
Removal of the rear suspension rocker arm 56
Overhauling the rear suspension rocker arm 57
Disassembly and overhaul of the shock absorber tie-rod 58
Refitting the rear suspension 59
