N 9.1
184 1098/1098S - M.Y. 2007 - edition 00
Engine
Unscrew and remove the oil filter support nipple (6) and remove also by-pass spring (7).
Remove the mesh filter (A) with its seal from the right-hand crankcase half (Sect. D 4).
Remove the drain plug (10) with its seal (9).
Remove the neutral switch (4) with its seal (3).
7
6
A
10
9
4
3
