section
N 9.1
1851098/1098S - M.Y. 2007 - edition 00
Engine
Remove the cylinder head studs (5) with the aid of the appropriate tool.
To remove the engine sensor (23), unscrew the bolt (25) and recover the shim (24) and the washer (26).
Check the condition of O-rings (22) and renew them if necessary.
If the engine sensor is to be renewed, it will be necessary to check the air gap as indicated in the paragraph “Checking the engine
sensor air gap”.
5
5
5
5
5
5
25
24
26
23
22
