Composite Output Format Table
CONV1 and 2 output signals
Output signal from COMPOSITE connector
525/60
CONV signals in 525/60
625/50
CONV signals in 625/50
1080/59i
B.B. in 525/60
1080/50i
B.B. in 625/50
1080/24PsF
B.B. in 625/50
1080/23.98PsF
B.B. in 525/60
720/59p
B.B. in 525/60
720/50p
B.B. in 625/50
1080/59p
B.B. in 525/60
1080/50p
B.B. in 625/50
YPbPr/RGB Output Format
FS1 or 2 output signal
FA-95AIO YPbPr/RGB
output signal
525/60
525/60 signal in FS 1 or 2
625/50
625/50 signal in FS 1 or 2
1080/59i
1080/59i signal in FS 1 or 2
1080/50i
1080/50i signal in FS 1 or 2
1080/24PsF
1080/24PsF signal in FS 1 or 2
1080/23.98PsF
1080/23.98PsF signal in FS 1 or 2
720/59p
720/59p signal in FS 1 or 2
720/50p
720/50p signal in FS 1 or 2
1080/59p
1080/59i black video
1080/50p
1080/50i black video
Y/C Output format
FS 1 or 2 output signal
Y/C output signal
525/60
525/60 signal in FS 1 or 2
625/50
625/50 signal in FS 1 or 2
1080/59i
525/60 BB signal
1080/50i
625/50 BB signal
1080/24PsF
625/50 BB signal
1080/23.98PsF
525/60 BB signal
720/59p
525/60 BB signal
720/50p
625/50 BB signal
1080/59p
525/60 BB signal
1080/50p
625/50 BB signal
