Parameter
Default
Setting range
Description
Program
Config
-
Dolby E 5.1+2
Dolby E 5.1+2x1
Dolby E 4+4
Dolby E 4+2x2
Dolby E 4+2+2x1
Dolby E 4+4x1
Dolby E 4x2
Dolby E 3x2+2x1
Dolby E 2x2+4x1
Dolby E 2+6x1
Dolby E 8x1
Dolby E 5.1
Dolby E 4+2
Dolby E 4+2x1
Dolby E 3x2
Dolby E 2x2+2x1
Dolby E 2+4x1
Dolby E 6x1
Dolby E 4
Dolby E 2+2
Dolby E 2+2x1
Dolby E 4x1
Dolby E 7.1
Dolby E 7.1Screen
NON-Dolby E
Displays Dolby E program configuration
(Coding mode) or status of signal
selected under Dolby Input.
See Dolby E/Digital Decoder Output
Channel Assignment table in section 12
“Analog Audio Connection” for channel
assignments of respective configurations.
Dolby Digital 1+1
Dolby Digital 1/0
Dolby Digital 2/0
Dolby Digital 3/0
Dolby Digital 2/1
Dolby Digital 3/1
Dolby Digital 2/2
Dolby Digital 3/2
Dolby Digital 3/0L
Dolby Digital 2/1L
Dolby Digital 3/1L
Dolby Digital 2/2L
Dolby Digital 3/2L
Loss
Invalid
 Dolby Decoder REF Input Select
Parameter
Default
Setting range
Description
REF Input
AUX REF IN
None
FS1 Output
FS2 Output
AUX REF In
FS1 Input
FS2 Input
Selects a reference signal to be used in the
Dolby decoder. PCM signal output from the
Dolby decoder will be synchronized to the
selected reference signal.
None: No reference signal used
FS1 Output: Uses the FS1 output video signal.
FS2 Output: Uses the FS2 output video signal.
AUX REF In: Uses the input signal in the
optional Dolby reference input connector (REF
IN). If no signal is in the REF IN connector, the
PCM signal output will be in free-run mode.
FS1 Input: Uses the FS1 input video signal.
FS2 Input: Uses the FS2 input video signal.
 Dolby Down Mix Mode
Parameter
Default
Setting range
Description
Mode
Surround
Surround
Stereo
Monaural
Selects a downmix mode for the
Dolby decoder.
