FOR-A FA-9520 - Page 255

255
Object group
Front TITLE
Item name
Settings
Object name in MIB file
OID
Type
Read
(Get)
Write
(Set)
OID: 1.3.6.1.4.1.20175.1.301.3.4.8. (fa952AudioEmb2OutGain)
EMB2 AUDIO
EMB2 OUT GAIN
Master Output Gain
-20.0 to 20.0 dB
fa952Embedded2MasterOutGain
1
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.4.8.2.1. (fa952AudioEmb2OutGain)
EMB2 AUDIO
EMB2 OUT GAIN
Channel
1 to 16
fa952Embedded2OutGainCh
1
INTEGER
-
-
Input Gain Offset CH
-40.0 to 40.0 dB
fa952Embedded2OutGainOffset
2
INTEGER
○
○
Input Gain Total CH
-20.0 to 20.0 dB
fa952Embedded2OutGainTotal
3
INTEGER
○
-
OID: 1.3.6.1.4.1.20175.1.301.3.4.9. (fa952AudioAesOutGain)
AES AUDIO
AES OUT GAIN
Master Output Gain
-20.0 to 20.0 dB
fa952AesMasterOutGain
1
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.4.9.2.1. (fa952AesOutGainEntry)
AES AUDIO
AES OUT GAIN
Channel
1 to 8
fa952AesOutGainCh
1
INTEGER
-
-
Input Gain Offset CH
-40.0 to 40.0 dB
fa952AesOutGainOffset
2
INTEGER
○
○
Input Gain Total CH
-20.0 to 20.0 dB
fa952AesOutGainTotal
3
INTEGER
○
-
OID: 1.3.6.1.4.1.20175.1.301.3.4.10. (fa952AudioAnalogOutGain)
ANALOG AUDIO
ANALOG OUT GAIN
Master Output Gain
-20.0 to 20.0 dB
fa952AnalogMasterOutGain
1
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.4.10.2.1 (fa952AnalogOutGainEntry)
ANALOG AUDIO
ANALOG AUDIO
GAIN
Channel
1 to 4
fa952AnalogOutGainCh
1
INTEGER
-
-
Input Gain Offset CH
-40.0 to 40.0 dB
fa952AnalogOutGainOffset
2
INTEGER
○
○
Input Gain Total CH
-20.0 to 20.0 dB
fa952AnalogOutGainTotal
3
INTEGER
○
-
OID: 1.3.6.1.4.1.20175.1.301.3.6.1. (fa952AudioEmb1Delay)
AUDIO DELAY
EMB1 IN DELAY
Audio Master Delay
4 to 1000 msec
fa952Embedded1MasterDelay
1
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.6.1.2.1. (fa952Emb1DelayEntry)
EMB1 IN DELAY
EMB1 IN DELAY
Channel
1 to 16
fa952Embedded1DelayCh
1
INTEGER
-
-
Audio Delay Offset
-996 to 996 msec
fa952Embedded1DelayOffset
2
INTEGER
○
○
Audio Delay Total
4 to 1000 msec
fa952Embedded1DelayTotal
3
INTEGER
○
-
OID: 1.3.6.1.4.1.20175.1.301.3.6.2. (fa952AudioEmb2Delay)
EMB2 IN DELAY
EMB2 IN DELAY
Audio Master Delay
4 to 1000 msec
fa952Embedded2MasterDelay
1
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.6.2.2.1. (fa952Emb2DelayEntry)
EMB2 IN DELAY
EMB2 IN DELAY
Channel
1 to 16
fa952Embedded2DelayCh
1
INTEGER
-
-
Audio Delay Offset
-996 to 996 msec
fa952Embedded2DelayOffset
2
INTEGER
○
○
Audio Delay Total
4 to 1000 msec
fa952Embedded2DelayTotal
3
INTEGER
○
-
OID: 1.3.6.1.4.1.20175.1.301.3.6.3. (fa952AudioAesDelay)
AES IN DELAY
AES IN DELAY
Audio Master Delay
4 to 1000 msec
fa952AesMasterDelay
1
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.6.3.2.1. (fa952AesDelayEntry)
AES IN DELAY
AES IN DELAY
Channel
1 to 8
fa952AesDelayCh
1
INTEGER
-
-
Audio Delay Offset
-996 to 996 msec
fa952AesDelayOffset
2
INTEGER
○
○
Audio Delay Total
4 to 1000 msec
fa952AesDelayTotal
3
INTEGER
○
-
OID: 1.3.6.1.4.1.20175.1.301.3.6.4. (fa952AudioAnalogDelay)
AUDIO DELAY
ANALOG IN DELAY
Audio Master Delay
4 to 1000 msec
fa952AnalogMasterDelay
1
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.6.4.2.1 (fa952AudioAnalogDelayEntry)
ANALOG IN
DELAY
ANALOG IN DELAY
Channel
1 to 4
fa952AnalogDelayCh
1
INTEGER
-
-
Audio Delay Offset
-996 to 996 msec
fa952AnalogDelayOffset
2
INTEGER
○
○
Audio Delay Total
4 to 1000 msec
fa952AnalogDelayTotal
3
INTEGER
○
-
OID: 1.3.6.1.4.1.20175.1.301.3.8.1. (fa952AudioEmb1Polarity)
AUDIO MODE
EMB1 POLARITY
Output Polarity CH1
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh1
1
INTEGER
○
○
Output Polarity CH2
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh2
2
INTEGER
○
○
Output Polarity CH3
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh3
3
INTEGER
○
○
Output Polarity CH4
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh4
4
INTEGER
○
○
Output Polarity CH5
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh5
5
INTEGER
○
○
Output Polarity CH6
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh6
6
INTEGER
○
○
Output Polarity CH7
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh7
7
INTEGER
○
○
Output Polarity CH8
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh8
8
INTEGER
○
○
Output Polarity CH9
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh9
9
INTEGER
○
○
Output Polarity CH10
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh10
10
INTEGER
○
○
Output Polarity CH11
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh11
11
INTEGER
○
○
Output Polarity CH12
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh12
12
INTEGER
○
○
Output Polarity CH13
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh13
13
INTEGER
○
○
Output Polarity CH14
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh14
14
INTEGER
○
○
Output Polarity CH15
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh15
15
INTEGER
○
○
Output Polarity CH16
0: NORMAL
1: INVERT
fa952AudioEmbedded1PolarityCh16
16
INTEGER
○
○
OID: 1.3.6.1.4.1.20175.1.301.3.8.2. (fa952AudioEmb2Polarity)
AUDIO MODE
EMB2 POLARITY
Output Polarity CH1
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh1
1
INTEGER
○
○
Output Polarity CH2
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh2
2
INTEGER
○
○
Output Polarity CH3
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh3
3
INTEGER
○
○
Output Polarity CH4
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh4
4
INTEGER
○
○
Output Polarity CH5
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh5
5
INTEGER
○
○
Output Polarity CH6
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh6
6
INTEGER
○
○
Output Polarity CH7
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh7
7
INTEGER
○
○
Output Polarity CH8
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh8
8
INTEGER
○
○
Output Polarity CH9
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh9
9
INTEGER
○
○
Output Polarity CH10
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh10
10
INTEGER
○
○
Output Polarity CH11
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh11
11
INTEGER
○
○
Output Polarity CH12
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh12
12
INTEGER
○
○
Output Polarity CH13
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh13
13
INTEGER
○
○
Output Polarity CH14
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh14
14
INTEGER
○
○
Output Polarity CH15
0: NORMAL
1: INVERT
fa952AudioEmbedded2PolarityCh15
15
INTEGER
○
○
