Upon Receipt
Unpacking
FA-9520 units and their accessories are fully inspected and adjusted prior to shipment.
Operation can be performed immediately upon completing all required connections and
operational settings.
Check your received items against the packing lists below.
FA-9520
(Incl. ladder strap/retaining clip assembly)
EIA standard type (Including 4 screws.)
FA-9520/FA-9500 User Manuals (PDF)
Option
Redundant power supply unit (with AC cord and
AC cord retaining clip)
Digital audio expansion cable (to expand digital
audio I/O up to 8 inputs and 8 outputs.)
Normally installed in slot B.
Dolby E encoder
FA-95D-D option required for FA-95DE-E
installation.
Analog component I/O expansion card
(with dedicated connection cable: PC-3307-1)
Automatic Loudness Adjustment card
Remote Control Unit for color correction.
* In FA-9520 mode, FA-95D-D, FA-95DE-E, FA-95AIO and FA-95ALA option cards can be
installed into either or both option slots A and B. In FA-9500 mode, only the card in slot A is
effective, if 2 of the same option cards are installed into both slots. Also, only the card in slot
A is effective, when FA-95D-D and FA-95DE-E are installed into both slots.
The FA-95DACBL option can be installed into either option slot A or B, however, not into both
slots.
Software Option
* FA-95CO is effective only in FA-9500 mode.
Software installation can be verified in the “SOFT OPTION1” and “SOFT OPTION2” menus.
The FA-9520 has 2 operational modes; FA-9500 mode, in which the unit
operates/functions almost the same as the former FA-9500, and FA-9520 mode with 2
independently operational frame synchronizers. After purchase, select an FA-9520
operational mode for the first time. Refer to section 7-1 “MU OPERATION” for details
on the mode selection procedure. This operation manual describes the operation in
FA-9520 mode. When operating in FA-9500 mode, refer to the separate FA-9520
operation manual (FA-9500 mode).
