Bit Offset Address Description
• Set this bit to 0 to request control of the internal configuration
bus by user.
• Set this bit to 1 to pass the internal configuration bus control to
PreSICE.
[1] 0x0 This bit indicates whether or not calibration is done. This is the
inverted cal_busy signal. You can write to this bit; however, if
you accidentally write 0x0 without enabling any calibration bit in
0x100, PreSICE may not set this bit to 0x1, and cal_busy remain
high. Channel reset is triggered if cal_busy is connected to the
reset controller.
• 0x1 = calibration completed.
• 0x0 = calibration not completed.
The cal_busy signal is activated two clock cycles after you
write 0x0 to this bit.
Note: During calibration when Nios is controlling the internal configuration bus, you can not
read offset address 0x0. However, you can write 0x0 to offset address 0x0[0] to
request bus access.
7.2.2. Transceiver Channel Calibration Registers
Table 297. Transceiver Channel PMA Calibration Registers
Bit PMA Calibration Enable Register Offset Address 0x100
0 Reserved
1 PMA RX calibration enable
2 Reserved
3 Reserved
4 Reserved
5 PMA TX calibration enable
6 Write 1'b0 to 0x100 [6] when you enable any PMA channel calibration to ensure adaptation
triggering request is disable.
7 Reserved
7.2.3. Fractional PLL Calibration Registers
Table 298. Fractional PLL Calibration Registers
Bit fPLL Calibration Enable Register Offset Address 0x100
0 Reserved
1 fPLL calibration enable. Set 1 to enable calibration.
(64)
The transceiver channel, ATX PLL, and fPLL use the same offset address.
