Intel Arria 10 User Manual

Parameter Value
Enable control and status registers Off
Enable prbs soft accumulators Off
Configuration file prefix
altera_xcvr_native_a10
Generate SystemVerilog package file Off
Generate C header file Off
Generate MIF (Memory Initialization File) Off
Table 210. Generation Options
Parameter Value
Generate parameter documentation file On
2.9. Other Protocols
2.9.1. Using the "Basic (Enhanced PCS)" and "Basic with KR FEC"
Configurations of Enhanced PCS
You can use Arria 10 transceivers to configure the Enhanced PCS to support other 10G
or 10G-like protocols. The Basic (Enhanced PCS) transceiver configuration rule allows
access to the Enhanced PCS with full user control over the transceiver interfaces,
parameters, and ports.
You can configure the transceivers for Basic functionality using the Native PHY IP
Basic (Enhanced PCS) transceiver configuration rule.
Basic with KR FEC is a KR FEC sublayer support with a low latency physical coding
sublayer (PCS). The KR FEC sublayer increases the bit error rate (BER) performance of
a link. This mode can run up to a data rate of 25.8 Gbps. Use this configuration to
implement applications with low latency or low BER requirements or applications such
as 10 Gbps, 40 Gbps or 100 Gbps Ethernet over backplane (10GBASE-KR protocol).
The Forward Error Correction (FEC) function is defined in Clause 74 of IEEE
802.3ap-2007. FEC provides an error detection and correction mechanism that allows
noisy channels to achieve the Ethernet-mandated Bit Error Rate (BER) of 10
-12
. The
FEC sublayer provides additional link margin by compensating for variations in
manufacturing and environmental conditions. To distinguish it from other FEC
mechanisms (for example, Optical Transport Network FEC), FEC as defined in Clause
74 of IEEE 802.3ap-2007 is called KR FEC.
Note: This configuration supports the FIFO in phase compensation and register modes, and
KR FEC PCS blocks. You can implement all other required logic for your specific
application, such as standard or proprietary protocol multi-channel alignment, either
in the FPGA fabric in soft IP or use Intel's 10GBASE-KR PHY IP core product as full
solutions in the FPGA.
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
289

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
