2.5.5. Native PHY IP Parameter Settings for Interlaken
This section contains the recommended parameter values for this protocol. Refer to
Using the Arria 10 Transceiver Native PHY IP Core for the full range of parameter
values.
Table 76. General and Datapath Parameters
Parameter Value
Message level for rule violations error
warning
Transceiver configuration rules Interlaken
PMA configuration rules basic
Transceiver mode TX / RX Duplex
TX Simplex
RX Simplex
Number of data channels 1 to 96
Data rate Up to 17.4 Gbps for GX devices
(Depending on Enhanced PCS to PMA interface width
selection)
Enable datapath and interface reconfiguration On / Off
Enable simplified data interface On / Off
Provide separate interface for each channel On / Off
Table 77. TX PMA Parameters
Parameter Value
TX channel bonding mode Not bonded
PMA-only bonding
PMA and PCS bonding
PCS TX channel bonding master If TX channel bonding mode is set to PMA and PCS
bonding, then:
Auto, 0, 1, 2, 3 through [Number of data channels – 1]
Actual PCS TX channel bonding master If TX channel bonding mode is set to PMA and PCS
bonding, then:
0, 1, 2, 3 through [Number of data channels – 1]
TX local clock division factor If TX channel bonding mode is not bonded, then:
1, 2, 4, 8
Number of TX PLL clock inputs per channel If TX channel bonding mode is not bonded, then:
1, 2, 3, 4
Initial TX PLL clock input selection 0
Enable tx_pma_clkout port On / Off
Enable tx_pma_div_clkout port On / Off
tx_pma_div_clkout division factor When Enable tx_pma_div_clkout port is On, then:
Disabled, 1, 2, 33, 40, 66
Enable tx_pma_elecidle port On / Off
Enable tx_pma_qpipullup port (QPI) Off
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
107
