Intel Arria 10 User Manual

Protocol Transceiver PHY IP
Core
PCS Support Transceiver
Configuration Rule
(9)
Protocol Preset
(10)
CPRI 9.8 Gbps Manual
Mode
SRIO 2.2/1.3 Native PHY IP core Standard Basic/Custom with
Rate Match(Standard
PCS)
Serial Rapid IO 1.25
Gbps
SAS 3.0 Native PHY IP core Enhanced Basic (Enhanced PCS) User created
SATA 3.0/2.0/1.0 and
SAS 2.0/1.1/1.0
Native PHY IP core Standard Basic/Custom
(Standard PCS)
SAS Gen2/Gen1.1/
Gen1
SATA Gen3/Gen2/
Gen1
HiGig/HiGig+/HiGig2/
HiGig2+
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
JESD204A / JESD204B Native PHY IP core Standard and
Enhanced
Basic/Custom
(Standard PCS) Basic
(Enhanced PCS)
(21)
User created
ASI Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
SPI-5 (100G) / SPI-5
(50G)
Native PHY IP core Enhanced Basic (Enhanced PCS) User created
Custom and other
protocols
Native PHY IP core Standard and
Enhanced
PCS Direct
Basis/Custom
(Standard PCS)
Basic (Enhanced PCS)
Basic/Custom with
Rate Match (Standard
PCS)
PCS Direct
User created
Related Information
• Using the Arria 10 Transceiver Native PHY IP Core on page 45
• AN745: Design Guidelines for DisplayPort and HDMI Interfaces
2.4. Using the Arria 10 Transceiver Native PHY IP Core
This section describes the use of the Intel-provided Arria 10 Transceiver Native PHY IP
core. This Native PHY IP core provides direct access to Arria 10 transceiver PHY
features.
Use the Native PHY IP core to configure the transceiver PHY for your protocol
implementation. To instantiate the IP, click Tools ➤ IP Catalog to select your IP core
variation. Use the Parameter Editor to specify the IP parameters and configure the
PHY IP for your protocol implementation. To quickly configure the PHY IP, select a
(9)
For more information about Transceiver Configuration Rules, refer to Using the Intel Arria
10Transceiver Native PHY IP Core section.
(10)
For more information about Protocol Presets, refer to Using the Intel Arria 10Transceiver
Native PHY IP Core section.
(21)
For JESD204B, Enhanced PCS is used when the data rate is above 12.0 Gbps
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
45
