Syntax
set_instance_assignment -name XCVR_A10_TX_SLEW_RATE_CTRL <value>
-to <tx_serial_data pin name>
Note: Currently, the Quartus Prime software doesn't choose the default values for Non-PCIe
mode. You must specify the setting in the .qsf file.
8.7. Transmitter Pre-Emphasis Analog Settings
The programmable pre-emphasis block in the transmit buffer amplifies the high
frequencies in the transmit data to compensate for attenuation in the transmission
media.
Note: Ignore all the pre-emphasis QSF assignments for PCIe Gen1 and Gen2 if your
transceiver link is within the PCI Express spec requirements. Quartus Prime assigns
default values for these parameters.
8.7.1. XCVR_A10_TX_PRE_EMP_SIGN_PRE_TAP_1T
Pin planner or Assignment Editor Name
Transmitter Pre-Emphasis First Pre-Tap Polarity
Description
Controls the polarity of the first pre-tap for pre-emphasis. The default value is
FIR_PRE_1T_NEG.
Table 321. Available Options
Value Description
FIR_PRE_1T_POS Positive pre-tap 1
FIR_PRE_1T_NEG Negative pre-tap 1
Assign To
TX serial data pin.
Syntax
set_instance_assignment -name XCVR_A10_TX_PRE_EMP_SIGN_PRE_TAP_1T
<value> -to <tx_serial_data pin name>
8.7.2. XCVR_A10_TX_PRE_EMP_SIGN_PRE_TAP_2T
Pin Planner or Assignment Editor Name
Transmitter Pre-Emphasis Second Pre-Tap Polarity
Description
Controls the polarity of the second pre-tap for pre-emphasis. The default value is
FIR_PRE_2T_NEG.
8. Analog Parameter Settings
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
600
