Assignment Pin Planner or Assignment
Editor Name
Value Description
XCVR_A10_RX_ADP_DFE_FX
TAP9_SGN
Receiver Decision Feedback
Equalizer Fixed Tap Nine
Sign
RADP_DFE_FXTAP9_SGN_
<0 or 1>
DFE fixed tap 9 coefficient
sign 0 or 1
0 = Positive and 1=Negative
XCVR_A10_RX_ADP_DFE_FX
TAP10
Receiver Decision Feedback
Equalizer Fixed Tap Ten
Coefficient.
RADP_DFE_FXTAP10_<0 to
63>
DFE fixed tap 10 Coefficient
Setting <0 to 63>
XCVR_A10_RX_ADP_DFE_FX
TAP10_SGN
Receiver Decision Feedback
Equalizer Fixed Tap Ten Sign
RADP_DFE_FXTAP10_SGN_
<0 or 1>
DFE fixed tap 10 coefficient
sign 0 or 1
0 = Positive and 1=Negative
XCVR_A10_RX_ADP_DFE_FX
TAP11
Receiver Decision Feedback
Equalizer Fixed Tap Eleven
Coefficient
RADP_DFE_FXTAP11_<0 to
63>
DFE fixed tap 11 Coefficient
Setting <0 to 63>
XCVR_A10_RX_ADP_DFE_FX
TAP11_SGN
Receiver Decision Feedback
Equalizer Fixed Tap Eleven
Sign
RADP_DFE_FXTAP11_SGN_
<0 or 1>
DFE fixed tap 11 coefficient
sign 0 or 1
0 = Positive and 1=Negative
Example DFE Fixed Tap Assignment
Assignment: XCVR_A10_RX_ADP_DFE_FXTAP1
Value: RADP_DFE_FXTAP1_2
Description: DFE fixed tap 1 Coefficient Setting 2
Assign To
RX serial data pin.
Syntax
set_instance_assignment -name XCVR_A10_RX_ADP_DFE_FXTAP1 <value>
-to <rx_serial_data pin name>
8.6. Transmitter General Analog Settings
8.6.1. XCVR_A10_TX_LINK
Pin planner or Assignment Editor Name
Transmitter Link Type
Description
This parameter is configured depending on the link characteristics. Value SR is used
for link insertion loss less than or equal to 10dB and value LR is used for link insertion
loss greater than 10dB. If this QSF assignment is not done, Quartus Prime assigns SR
as the default value. This is used for data rate legality check during compilation.
8. Analog Parameter Settings
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
596
