Related Information
Quartus Prime Settings File (.qsf)
Describes the commands and options available to modify the assignments in the
qsf file.
8.3. Analog Parameter Settings List
The following table lists the analog parameter settings for the transmitter and receiver.
The details of each of these settings are in the sections following this table.
Table 304. Receiver Analog Parameter Settings
Analog Parameter Setting Pin Planner or Assignment Editor
Name
Assignment
Destination
Usage Guideline
XCVR_A10_RX_LINK Receiver Link Type RX serial data Chip-to-chip or backplane
XCVR_A10_RX_TERM_SEL Receiver On-Chip-Termination RX serial data On chip termination
XCVR_VCCR_VCCT_VOLTAGE VCCR_GXB/VCCT_GXB Voltage RX serial data VCCR/VCCT voltage
XCVR_A10_RX_ONE_STAGE_ENABL
E
Receiver High Data Rate Mode
Equalizer
RX serial data Continuous time-linear
equalization (CTLE)
XCVR_A10_RX_EQ_DC_GAIN_TRIM Receiver High Gain Mode Equalizer
DC Gain Control
RX serial data CTLE
XCVR_A10_RX_ADP_CTLE_ACGAIN
_4S
Receiver High Gain Mode Equalizer
AC Gain Control
RX serial data CTLE
XCVR_A10_RX_ADP_CTLE_EQZ_1S
_SEL
Receiver High Data Rate Mode
Equalizer AC Gain Control
RX serial data CTLE
XCVR_A10_RX_ADP_VGA_SEL Receiver Variable Gain Amplifier
Voltage Swing Select
RX serial data VGA
XCVR_A10_RX_ADP_DFE_FXTAP1 Receiver Decision Feedback
Equalizer Fixed Tap One Coefficient
RX serial data Decision feedback
equalization (DFE)
XCVR_A10_RX_ADP_DFE_FXTAP2 Receiver Decision Feedback
Equalizer Fixed Tap Two Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP2_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Two Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP3 Receiver Decision Feedback
Equalizer Fixed Tap Three
Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP3_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Three Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP4 Receiver Decision Feedback
Equalizer Fixed Tap Four Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP4_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Four Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP5 Receiver Decision Feedback
Equalizer Fixed Tap Five Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP5_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Five Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP6 Receiver Decision Feedback
Equalizer Fixed Tap Six Coefficient
RX serial data DFE
continued...
8. Analog Parameter Settings
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
586

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
