Intel Arria 10 User Manual

2.7.10. ATX PLL Ports for PIPE
Table 193. ATX PLL Ports for PIPE
This section contains the recommended settings for this protocol. Refer to Using the Arria 10 Transceiver
Native PHY IP Core for the full range of parameter settings.
Port Direction Clock Domain Description
Pll_powerdown
Input Asynchronous Resets the PLL when asserted high. Needs to be connected to a
dynamically controlled signal (the Transceiver PHY Reset
Controller pll_powerdown output if using this Intel FPGA IP.
Pll_reflck0
Input N/A Reference clock input port 0. There are five reference clock
input ports. The number of reference clock ports available
depends on the Number of PLL reference clocks parameter.
tx_serial_clk
Output N/A High speed serial clock output port for GX channels. Represents
the x1 clock network.
For Gen1x1, Gen2x1, connect the output from this port to the
tx_serial_clk input of the native PHY IP.
For Gen1x2, x4, x8, use the tx_bonding_clocks output port to
connect to the Native PHY.
For Gen2x2, x4, x8, use the tx_bonding_clocks output port to
connect to the Native PHY.
For Gen3x1, connect the output from this port to one of the two
tx_serial_clk input ports on the native PHY IP.
For Gen3x2, x4, x8, this port is not used. Use the tx_serial_clk
output from the fPLL to drive the Auxiliary Master CGB clock
input port of the ATX PLL.
pll_locked
Output Asynchronous Active high status signal which indicates if PLL is locked.
pll_pcie_clk
Output N/A This is the hclk required for PIPE interface.
For Gen1x1,x2,x4,x8 use this port to drive the hclk for the PIPE
interface.
For Gen2x1,x2,x4,x8 use this port to drive the hclk for the PIPE
interface.
For Gen3x1,x2,x4,x8, this port is not used. Use the
pll_pcie_clk from fPLL (configured as Gen1/Gen2) as the
hclk for the PIPE interface.
Pll_cal_busy
Output Asynchronous Status signal which is asserted high when PLL calibration is in
progress. If this port is not enabled in the Transceiver PHY
Reset Controller, then perform logical OR with this signal and
the tx_cal_busy output signal from Native PHY to input the
tx_cal_busy on the reset controller IP.
Mcgb_rst
Input Asynchronous Master CGB reset control.
mcgb_aux_clk0
Input N/A Used for Gen3 to switch.
between fPLL/ATX PLL during link speed negotiation.
For gen3x2,x4,x8 use the tx_serial_clk output port from
fPLL (configured for Gen1/Gen2) to drive the mcgb_aux_clk
input port on the ATX PLL.
tx_bonding_clocks[5:0]
Output N/A Optional 6-bit bus which carries the low speed parallel clock
outputs from the Master CGB. Used for channel bonding, and
represents the x6/xN clock network.
For Gen1x1, this port is disabled.
For Gen1x2,x4,x8 connect the output from this port to the
tx_bonding_clocks input on Native PHY.
For Gen2x1, this port is disabled
For Gen2x2,x4,x8 connect the output from this port to
tx_bonding_clocks input on Native PHY.
For Gen3x1, this port is disabled.
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
266
