Intel Arria 10 User Manual

Port Direction Clock Domain Description
For Gen3x2,x4,x8 use the tx_bonding_clocks output from
the ATX PLL to connect to the tx_bonding_clocks input of
the Native PHY.
pcie_sw[1:0]
Input Asynchronous 2-bit rate switch control input used for PCIe protocol
implementation.
For Gen1, this port is N/A.
For Gen 2x2,x4,x8 connect the pipe_sw output from Native
PHY to this port.
For Gen3x2,x4,x8 use the pipe_sw output from Native PHY to
drive this port.
pcie_sw_done[1:0]
Output Asynchronous 2-bit rate switch status output used for PCIe protocol
implementation.
For Gen1, this port is N/A.
For Gen2x2, x4, x8 connect the pcie_sw_done output from
ATX PLL to pipe_sw_done input of Native PHY .
For Gen3x2, x4, x8 pcie_sw_done output from ATX PLL to
pipe_sw_done input of Native PHY.
Related Information
Using the Arria 10 Transceiver Native PHY IP Core on page 45
2.7.11. Preset Mappings to TX De-emphasis
Table 194. Arria 10 Preset Mappings to TX De-emphasis
Preset C
+1
C
0
C
-1
0 001111 101101 000000
1 001010 110010 000000
2 001100 110000 000000
3 001000 110100 000000
4 000000 111100 000000
5 000000 110110 000110
6 000000 110100 001000
7 001100 101010 000110
8 001000 101100 001000
9 000000 110010 001010
10 010110 100110 000000
The pipe_g3_txdeemph port is used to select the link partner’s transmitter de-
emphasis during equalization. The 18 bits specify the following coefficients:
[5:0]: C
-1
[11:6]: C
0
[17:12]: C
+1
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
267
