1.1.3. Arria 10 GX and GT Device Package Details
The following tables list package sizes, available transceiver channels, and PCI Express
Hard IP blocks for Arria 10 GX and GT devices.
Table 3. Package Details for GX Devices with Transceivers and Hard IP Blocks Located
on the Left Side Periphery of the Device
• Package U19: 19mm x 19mm package; 484 pins.
• Package F27: 27mm x 27mm package; 672 pins.
• Package F29: 29mm x 29mm package; 780 pins.
• Packages F34 and F35: 35 mm x 35 mm package size; 1152 pins.
• Package F40: 40 mm x 40 mm package size; 1517 pins. K = 36 transceiver channels, N = 48 transceiver
channels.
Device U19 F27 F29 F34 F35 K F40 N F40
Transceiver Count, PCIe Hard IP Block Count
GX 016 6, 1 12, 1 12, 1
GX 022 6, 1 12, 1 12, 1
GX 027 12, 1 12, 1 24, 2 24, 2
GX 032 12, 1 12, 1 24, 2 24, 2
GX 048 12, 1 24, 2 36, 2
GX 057 24, 2 36, 2 36, 2 48, 2
GX 066 24, 2 36, 2 36, 2 48, 2
GX 090 24, 2 48, 2
GX 115 24, 2 48, 2
Table 4. Package Details for GX and GT Devices with Transceivers and Hard IP Blocks
Located on the Left and Right Side Periphery of the Device
• Package F40: 40 mm x 40 mm package size; 1517 pins. R = 66 transceiver channels.
• Package F45: 45mm x 45mm package size; 1932 pins. N = 48 transceiver channels, S = 72 transceiver
channels, U = 96 transceiver channels.
• If you're using GT transceivers in bank GXBL1E, the nth adjacent PCIe Hard IP block cannot be used.
Device
R F40 N F45 S F45 U F45
Transceiver Count, PCIe Hard IP Block Count
GX 090 66, 3 48, 4 72, 4 96, 4
GX 115 66, 3 48, 4 72, 4 96, 4
GT 090 72, 4
GT 115 72, 4
1.1.4. Arria 10 SX Device Transceiver Layout
The largest SX device includes 48 transceiver channels. All SX devices include GX
transceiver channel type. The transceiver banks in SX devices are located on the left
side periphery of the device.
