Feature Description
32-bit XGMII for 1G/2.5G/5G/10G (USXGMII).
64-bit XGMII for 10G.
Network-side interface 1.25 Gbps for 1G.
3.125 Gbps for 2.5G.
10.3125 Gbps for 1G/2.5G/5G/10G (USXGMII).
Avalon
®
Memory-Mapped (Avalon-MM)
interface
Provides access to the configuration registers of the PHY.
PCS function 1000BASE-X for 1G and 2.5G.
10GBASE-R for 10G.
USXGMII PCS for 1G/2.5G/5G/10G
Auto-negotiation Implements clause 37. Supported in 1GbE only.
USXGMII Auto-negotiation supported in the 1G/2.5G/5G/10G (USXGMII)
configuration.
IEEE 1588v2 Provides the required latency to the MAC if the MAC enables the IEEE
1588v2 feature.
Sync-E Provides the clock for Sync-E implementation.
2.6.5.1.2. Release Information
Table 152. PHY Release Information
Item Description
Version 16.0
Release Date May 2016
Ordering Codes IP-10GMRPHY
Product ID 00E4
Vendor ID 6AF7
Open Core Plus Supported
2.6.5.1.3. Device Family Support
Device Family
Operating Mode Support Level
Arria 10 2.5G
1G/2.5G
1G/2.5G/5G/10G
Final
Arria V GX/GT/SX/ST 2.5G
1G/2.5G
Final
Other device families No support
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
200

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
